Applications

• CATV
• Data

Features

• Aluminum alloy housing is finished with a baked acrylic paint
• FR4 PCB for consistency of specifications in all bandwidth
• High quality ferrites, SMD resistors and capacitors
• Return loss all ports: 5-750MHz:18dB,750-1000 MHz:16dB
• Hum modulation at 10 Amps: 70dB min
• All port power passing: 15 Amps 60VAC
• Impedance: 75Ω all ports
• Aerial or pedestal installation with 5/8” port entry
• The 100dB RF integrity is maintained by the use of tongue and groove design and with a stainless steel mesh RF gasket
