Applications

• CATV
• FTTX
• Data

Features

• 1000MHz bandwidth
• 50dBmV high level 4 output ports
• Selectable 2 or 4 RF ports
• With capability of field upgrade operation for redundant 2pcs of forward receiver or 2pcs of return transmitters
• Wide optical input operation range, -3dBm to +2dBm for standard optical input
• JXP PAD for level attenuation
• Linear equalizer using JXP PAD for slope adjustment
• Band diplexer selection for 42/54 , and 65/85
• With optical power TP and LED display for receiver and transmitter module
• Optional burst Mode operation in Return Transmitter
• 15A power current passing capability
